Molybdenum Wire Mesh

Product No.：2023320163014
Online Inquiry

Material:Black Molybdenum Wire—pure Molybdenum,with Graphite Coating

White Molybdenum Wire—without Graphite Coating

Color: White wire ,Black wire

Melting Point: 2610°C - 2640°C

Mesh:6-165Mesh

Woven style:Plain and Twill Weave

Features:High tensile strength.Low elongation.Acid and alkaline resistant.High temperature resistant.Wear resistant.Good,electricity-conductivity.Lightweight.Various hole shapes.Excellent filtering performance.

ApplicationMolybdenum wire mesh has good corrosion resistance, heat-conductivity and is widely used in high temperature field for sieving and filtering. The main application fields are:Aerospace.Nuclear power filed.Electro-vacuum industry.Glass furnaces.Petroleum.Oil and gas industry.New energy industries.Food processing industry.

Common Specification
Wire Mesh(wires/In.)	Wire Diameter	Type Weave	Width Opening	%Open Area
6x6	0.0010	Plain	0.1567	88.4
8x8	0.0010	Plain	0.1150	84.6
8x8	0.0250	Plain	0.1000	64
8x8	0.0320	Plain	0.0930	55.4
10x10	0.0150	Plain	0.0850	73.2
20x20	0.0080	Plain	0.0420	70.6
20x20	0.0120	Plain	0.0380	57.8
26x26	0.0070	Plain	0.0315	66.9
30x30	0.0040	Plain	0.0293	77.4
30x30	0.0080	Plain	0.0253	57.8
40x40	0.0050	Plain	0.0200	64
50x50	0.0020	Plain	0.0180	81
50x50	0.0027	Plain	0.0173	74.8
60x60	0.0018	Plain	0.0149	79.6
60x60	0.0040	Plain	0.0127	57.8
60x60	0.0064	Twill	0.0103	38.0
80x80	0.0040	Plain	0.0085	46.2
100x100	0.0010	Plain	0.0090	81.0
100x100	0.0025	Plain	0.0075	56.3
165x165	0.0020	Twill	0.0041	44.9
